36V 100Ah LiFePO4 Lithium Golf Cart Battery Factory

36V 100Ah LiFePO4 Lithium Golf Cart Battery Factory

Production Info

• Cell: LiFePO4
• It Directly Applied to: Golf Carts, Sightseeing Vehicle, LSV, etc.
• MOQ: 10
• Delivery: 20 Days
• Customizable / OEM / ODM: Yes
• Factory: Redway Dongguan
• Delivery Terms: FOB, EXW, CIF
• Payment: T/T, L/C, PayPal
• Sea / Air / Land Shipment: 10FT, 20FT, 40FT, 60FT

Description

redway-battery-36v-100ah-lifepo4-golf-cart
redway-battery-36v-100ah-lifepo4-golf-cart
Redway Battery offers a full range of lithium batteries in BCI Group 24, Group 27, Group 31, Group 34, Group 35, Group 51, Group 51R, Group 78, Group 8D dimensions, etc. We are a professional lithium battery factory. We undertake OEM/ODM production of lithium battery, please Contact us.

RG38105 Specifications
Lithium Cell LiFePO4 (LFP)
Nominal Voltage 38.4V
Nominal Capacity 105Ah
Nominal Energy 4.03kWh
Max Charge Voltage 43.8V
Discharge Cut-off Voltage 30V
Max Continues Charge Current 100A
Max Continues Discharge Current 100A
Peak Discharge Current 200A (10S)
Dimensions
[L x W x H]
385 x 338 x 245 mm
15.2 x 13.3 x 9.6 inches
Weight 34 kg
75 lbs
IP Rating IP66
Communications RS485
Max Parallel Connections 4
Internal Resistance ≤10mΩ
Cycle Life >5000 cycles (80% DOD 0.5C)
Self-Discharge 3% (Per month)
Power Switch Yes
Charge Temperature 0 ~ 60°C
Discharge Temperature -20 ~ 65°C
Storage Temperature (1 Month) -20 ~ 45°C
Storage Temperature (1 Year) 0 ~ 35°C
Optional Upgrades Bluetooth / App / 4G / GPS / Self-heating / LCD Display / RS232 / CAN-bus / RJ45 / Active Balance / Cooling Fan / Circuit Breaker / Solar MPPT / etc.
Standard Charge Current 22A (5 hours)
BMS JBD / DALY BMS
Battery Shell Metal
Warranty 3 Years
Silkscreen / Label / Laser Logo Yes
User Manual Yes
OEM / ODM Yes
Shipment Yes
Design Life 10 Years
Certifications UL 1642 / IEC 62619 / CE / MSDS / UN38.3

redway-battery-slar

redway-battery-golf-carts-battery

redway-battery-golf-carts-battery

redway-battery-golf-carts-battery

Redway Battery OEM Factory Wholesale Price. Get a Quick Quote Now!

Specifications

RG38105 Specifications
Lithium Cell LiFePO4 (LFP)
Nominal Voltage 38.4V
Nominal Capacity 105Ah
Nominal Energy 4.03kWh
Max Charge Voltage 43.8V
Discharge Cut-off Voltage 30V
Max Continues Charge Current 100A
Max Continues Discharge Current 100A
Peak Discharge Current 200A (10S)
Dimensions
[L x W x H]
385 x 338 x 245 mm
15.2 x 13.3 x 9.6 inches
Weight 34 kg
75 lbs
IP Rating IP66
Communications RS485
Max Parallel Connections 4
Internal Resistance ≤10mΩ
Cycle Life >5000 cycles (80% DOD 0.5C)
Self-Discharge 3% (Per month)
Power Switch Yes
Charge Temperature 0 ~ 60°C
Discharge Temperature -20 ~ 65°C
Storage Temperature (1 Month) -20 ~ 45°C
Storage Temperature (1 Year) 0 ~ 35°C
Optional Upgrades Bluetooth / App / 4G / GPS / Self-heating / LCD Display / RS232 / CAN-bus / RJ45 / Active Balance / Cooling Fan / Circuit Breaker / Solar MPPT / etc.
Standard Charge Current 22A (5 hours)
BMS JBD / DALY BMS
Battery Shell Metal
Warranty 3 Years
Silkscreen / Label / Laser Logo Yes
User Manual Yes
OEM / ODM Yes
Shipment Yes
Design Life 10 Years
Certifications UL 1642 / IEC 62619 / CE / MSDS / UN38.3
